Запчасти Komatsu PC12UU-2 ПЕРЕДН. COVER ЧАСТИ КОРПУСА

|1

20C-46-21400

COVER ASS'Y

1

COVER,L.H.

2

20C-54-21830

SHEET

3

01010-51025

BOLT

4

21U-54-21760

WASHER

5

20C-54-21620

COVER

6

20C-54-21630

PLATE

7

20U-54-21570

CAP

7A

20U-54-21820

NUT

8

01435-01016

BOLT

9

20C-54-21640

COVER

10

20C-54-21650

PLATE

11

20U-54-21570

CAP

11A

20U-54-21820

NUT

12

20C-54-21660

HINGE

13

01010-51020

BOLT

14

01010-51025

BOLT

15

01643-31032

WASHER

16

21U-54-21610

LOCK ASS'Y

17

01010-51016

BOLT

18

01643-31032

WASHER

19

20C-54-21680

BRACKET

20

01010-51020

BOLT

21

01643-31032

WASHER

22

20C-54-21690

WIRE

23

01642-20810

WASHER

24

04205-10618

PIN

25

04052-10833

PIN,SNAP

26

04052-10633

PIN,SNAP

27

205-54-51970

DOVE TAIL

28

205-54-53550

DOVE TAIL

29

01435-00612

BOLT

30

20C-54-21810

SHEET

31

20C-54-21820

SHEET

|32

20C-46-21300

COVER ASS'Y

32

COVER,R.H.

33

20C-54-21850

SHEET

34

20C-54-21870

SHEET

35

20C-54-21950

SHEET

36

20C-54-21670

PLATE

37

01435-00820

BOLT

38

01010-51020

BOLT

39

01643-31032

WASHER
