Запчасти Komatsu PC12UU-2 МОТОР ПОВОРОТА (/) (ВНУТР. ЧАСТИ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20C-60-26800

SWING MOTOR ASS'Y

|1

20C-60-26820

HYDRAULIC MOTOR A.

1

BODY

2

BODY

3

SHAFT

4

BARREL,CYLINDER

5

PLATE,VALVE

6

PISTON

7

SHOE

8

HOLDER,SHOE

9

HOLDER,BARREL

10

PLATE,SWASH

11

RETAINER

12

20W-60-12650

PIN

13

20C-60-26640

FILTER

14

SPRING

15

20C-60-22650

BEARING

16

20W-60-12750

BEARING

17

07000-12120

O-RING

18

04065-02812

RING,SNAP

19

SPRING

20

04025-00512

PIN,SPRING

21

20W-60-12780

PIN

22

20W-60-12770

PIN

23

SPACER

24

PLATE,STEEL

25

PLATE,DISK

26

PISTON,BRAKE

27

20P-60-71360

RING,BACK-UP

28

07000-12100

O-RING

29

07000-12110

O-RING

30

20C-60-26830

RING,BACK-UP

31

01252-41030

BOLT
