Запчасти Komatsu PC12UU-2 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

20C-63-X2121

CYLINDER GROUP,ARM

|1

20C-63-02121

CYLINDER ASS'Y,ARM

1

20C-63-66243

CYLINDER

2

707-76-35210

BUSHING

3

07145-00035

SEAL,DUST (KIT)

4

07020-00900

FITTING,GREASE

5

707-29-70250

HEAD

6

707-51-40210

PACKING (KIT)

7

198-63-75190

SEAL,DUST (KIT)

8

07179-12052

RING,SNAP

9

07000-12065

O-RING (KIT)

10

07146-02066

RING,BACK-UP (KIT)

11

707-35-52640

RING,BACK-UP (KIT)

12

07000-02070

O-RING (KIT)

13

20C-63-66221

ROD

14

07144-10304

BUSHING

15

07145-00035

SEAL,DUST (KIT)

16

07020-00900

FITTING,GREASE

17

707-71-60470

PLUNGER

18

707-36-70560

PISTON

19

707-44-70180

RING,PISTON (KIT)

20

07156-00710

RING,WEAR (KIT)

21

707-40-70570

RETAINER

22

707-40-80310

SPACER

23

01580-02722

NUT

24

20C-63-66282

TUBE

25

707-88-80190

BOLT

26

01643-31032

WASHER

27

07042-20108

PLUG

28

707-88-10280

PLATE

29

01010-51016

BOLT

30

01643-51032

WASHER
