Запчасти Komatsu PC12R-8 МОТОР ПОВОРОТА УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

842140002

SWING MOTOR A.

\0

842360019

KIT, PINION

1

842360022

HOUSING

2

842360023

PINION

3

842360024

BEARING

4

842360025

BEARING

5

842360010

PLUG

6

GASKET

7

842360027

RING, SNAP

8

O-RING

\8

842360020

KIT, MOTOR

9

842360029

SHAFT FACE SEAL

10

842360030

COVER

11

O-RING

12

842360031

VALVE PLATE

13

O-RING

14

842360033

CONTROL VALVE

15

842360034

BALANCE PLATE

16

842360035

SPRING

17

SNAP RING

18

842360037

PIN

19

SNAP RING

20

842360039

SHAFT, CONTROL

21

842360040

STATOR

22

842360041

VALVE DRIVE

23

O-RING

24

842360043

HOUSING

25

842360044

BALL

26

842360045

PLUG

27

O-RING

28

842360047

SPRING

29

842360048

BOLT

30

842360010

PLUG

\30

842360051

KIT, VALVE

31

842360003

CARTRIDGE

32

842360004

VALVE SEAT

33

842360005

NEEDLE VALVE

34

842360006

VALVE SEAT

35

842360007

VALVE SEAT

36

842360008

ORIFICE

37

842360009

SEAL

38

842360010

PLUG

39

842360011

SPRING

\39

842360018

KIT, GASKET

40

O-RING

41

O-RING

42

842360014

SET SCREW

43

842360015

NUT

44

842360016

NUT

\44

842360017

KIT, GASKET

45

GASKET

46

O-RING

47

SHAFT FACE SEAL

48

O-RING

49

O-RING

50

INNER FACE SEAL

51

OUTER FACE SEAL

52

O-RING

53

O-RING
