Запчасти Komatsu PC12R-8 МАРКИРОВКА (КАБИНА) МАРКИРОВКА

Схема запчастей Komatsu PC12R-8 - МАРКИРОВКА (КАБИНА) МАРКИРОВКА
33
20
17
a
b
c
d
d
a
d
c
b
37
2
4
13
14
12
1
30
7
13
26
22
6
41
3
34
16
28
35
14
5
38
1
30
26
13
35
15
23
36
39
11
11
19
29
27
10
40
9
18
24
21
31
32
8
25

Артикул

Название

Примечание

Количество

\0

816215083

MARK PLATE KIT (PC12)

1

MARK PLATE KOMATSU

2

MARK PLATE KOMATSU

3

MARK PLATE, MISTRAL

4

MARK PLATE, MISTRAL

5

PLATE, CONTROLS LEVER, BOOM SWING, ATTACHMENT

6

PLATE, OPERATING, RAISING CAPACITY

7

PLATE LWA 904

8

PLATE LPA 76

9

PLATE, LUBRICATING TABLE

\9

816214546

KIT, MARK PLATE

10

PLATE, OPERATING, BLADE-FUEL CONTROL

11

PLATE, OPERATING, CONTROL LOCK

12

PLATE, SAFETY, DO NOT OPEN ENGINE HOOD

13

PLATE, LIFTING POINT

14

PLATE, SAFETY, KEEP OUT TURNING AREA

15

PLATE, SAFETY, HYDRAULIC OIL

16

PLATE, SAFETY, FUEL

17

PLATE, SAFETY, ENGINE OIL FILTER

18

PLATE, SAFETY FUEL FILTER

19

PLATE, SAFETY, ENGINE AIR FILTER

20

PLATE, SAFETY, RADIATOR CAP

21

PLATE, FITTING POINT

22

PLATE, SAFETY, HYDRAULIC OIL LEVEL

23

PLATE, SAFETY, HYDRAULIC OIL FILTER

24

PLATE, SAFETY, ELECTRIC SOCKET

25

PLATE, READ MANUAL

26

PLATE, RAISING POINT

27

PLATE, OPERATING SWING LOCK LEVER

28

MARK PLATE,OPTIONAL SWITCH

29

PLATE, UNLOCKING HOOD

30

MARK PLATE, UTILITY

31

3F05B2642

PLATE, NAME

32

801570027

RIVET

33

3F10B2610

PLATE, SAFETY, EMERGENCY EXIT

34

3F1042630

PLATE, OPERATING, PPC VALVE (R.H.)

35

802190004

WASHER

36

3F1042631

PLATE, OPERATING, PPC VALVE (L.H.)

37

3F10B2649

PLATE CLSS

38

3F05B2620

PLATE, CONTROL TABLE (WITH TRAVEL INCREMENT)

38

3F05B2656

PLATE, CONTROL TABLE (WITH 2-WAYS ATTACHMENT)

39

3F07B2625

PLATE, VARIABLE GAUGE UNDERCARRIAGE SELECTION

40

3F07B2626

PLATE, VARIABLE GAUGE UNDERCARRIAGE CONTROL

41

3F05B2657

PLATE, OPER., RAISING CAP.TY (VARIABLR GAUGE UNDER

Выбрано товаров: 44
