Запчасти Komatsu PC12R-8 РЕГУЛЯТОР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC12R-8 - РЕГУЛЯТОР ДВИГАТЕЛЬ
61
A
103
100
60
102
103
70
69
65
109
64
109
67
101
4
16
106
2
62
3
28
108
17
52
19
107
59
57
58
51
76
59
112
114
113
1
53
30
50
111
63
110
48
5
104
11
23
10
13
12
20
6
105
20
44
47
23
45
49
29

Артикул

Название

Примечание

Количество

\0

871070019

MOTOR, ASSY.

1

YM194990-22050

NUT

2

YM119660-61060

COVER

3

YM119660-61071

GASKET

4

YM26106-060702

SCREW

5

YM119266-61100

SET GOVERNOR

6

YM119600-61200

GOVERNOR WEIGHT, ASSY.

10

YM119660-61300

NUT

11

YM119660-61341

SLEEVE

12

YM119266-61230

SPACER

13

YM119660-61121

LINK L=88.8 mm

13

YM119660-61140

LINK L=88.6 mm

13

YM119660-61150

LINK L=89.0 mm

16

YM119632-61200

REGULATOR, ASSY.

17

YM129155-51280

O-RING

19

YM119660-61052

GASKET

20

YM119660-61460

SHIM

23

YM129155-61480

SPACER

28

YM119660-61491

SHAFT, GOVERNOR LEVER

29

YM119232-61510

LINK ASSY., GOVERNOR

30

YM174307-51700

KIT, SHIM

44

YM119232-61540

SPRING

45

YM119600-61541

SHIFTER

47

YM119660-61651

SPRING

48

YM22117-040000

WASHER

49

YM22272-000040

RING, SNAP

50

YM22351-030014

PEG

51

YM119600-61900

RETAINER, SHAFT

52

YM119660-61901

RETAINER, SHAFT

53

YM119285-66080

SHAFT, ASSY.

57

YM22351-040010

PIN

58

YM24341-000070

O-RING

59

YM26106-060102

BOLT PLATED

60

YM121465-59950

BOLT

61

YM26687-120002

CAP NUT

62

YM119256-66010

SPRING, REGULATOR

63

YM119621-66051

LEVER, GOVERNOR

64

YM124550-66370

NUT

65

YM119233-66511

STOP DEVICE

67

YM24341-000280

O-RING

69

YM26106-060952

BOLT

70

YM119640-66510

CONTROLLER, ASSY.

76

YM119610-66700

ANGLEICH, ASSY.

100

YM26776-120002

NUT

101

YM121575-66830

SCREW

102

YM119600-66840

NUT

103

YM22190-120002

SPRING WASHER

104

YM22360-040000

PIN, SNAP

105

YM22360-060000

PEG

106

YM26116-050102

BOLT PLATED

107

YM26116-060304

SCREW

108

YM26756-060002

NUT

109

YM22190-060003

GASKET

110

YM119840-61870

SPRING

111

YM119656-66910

HOOK

112

YM102100-67080

CHECK BOLT

113

YM26756-060002

NUT

114

YM26116-040088

SCREW

Выбрано товаров: 58
