Запчасти Komatsu PC12R-8 КАБИНА (/9) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20M-54-84163

CAB ASS'Y

2

PZF816214090

FRAME

3

PZF816024504

GLASS

4

PZF816214002

SEAL

5

PZF816214103

HANDLE

6

21D-09-16420

SCREW

7

01641-20508

WASHER

8

21D-54-13290

WASHER

9

PZF816214007

BRACKET

10

21D-54-13240

HANDLE

11

21D-09-15750

SCREW

12

21D-09-15740

SCREW

13

PZF802070006

WASHER

14

21D-54-13250

SPACER

15

21D-54-13260

LOCK ASS'Y

16

21D-54-13270

SEAL

17

21D-54-13140

HINGE

18

21D-54-13150

SEAL

19

21D-54-13190

SPACER

20

21D-54-13180

RUBBER

21

21D-54-13550

PLUG

22

21D-09-15170

BOLT

23

21D-09-15160

BOLT

24

PZF802070008

WASHER

25

PZF801703208

NUT

26

21D-09-86190

COVER

27

21D-54-13230

HANDLE

28

21D-09-15150

BOLT

29

21D-09-74460

WASHER

30

PZF816214004

SEAL

31

21D-54-13340

BRACKET

32

PZF816214006

COVER

33

21D-54-13330

NUT

34

21D-54-13320

PROTECTOR

35

21D-54-13310

PIN

36

21D-54-13980

BLOCK

37

21D-54-13990

SHIM

38

PZF816214049

SEAL

39

PZF816024508

GLASS

40

PZF816214047

SEAL

41

21D-54-13910

GLASS

42

PZF816024507

SEAL

43

21D-54-13220

PIN

44

21D-54-13210

BUSHING

45

21D-09-84170

PIN
