Запчасти Komatsu PC128UU-2 МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-73-01260

MOTOR ASS'Y

|1

706-73-03530

MOTOR SUB ASS'Y

1

706-73-43140

CASE,MOTOR

|2

706-73-00020

HOUSING SUB ASS'Y

2

HOUSING

3

PLUG

4

PLUG

5

706-73-40010

BEARING

6

706-73-42820

PIN

7

706-73-72680

PLUG

8

07002-11223

O-RING

|9

706-73-72710

VALVE SUB ASS'Y

9

706-73-72720

VALVE

10

706-73-72730

POPPET

11

706-73-72740

PLUG

12

706-73-72440

SPRING

13

706-73-72750

PLUG

14

07000-12020

O-RING

15

07001-02020

RING,BACK-UP

16

706-73-72420

VALVE

17

706-73-72440

SPRING

18

706-73-72430

PLUG

19

07002-12434

O-RING

20

07000-02145

O-RING

21

01252-61240

BOLT

22

706-73-43960

SHAFT,DRIVE

23

706-73-43880

BEARING

24

706-73-43810

SPACER

25

706-73-43610

SPRING

26

706-73-43620

SEAT

27

706-73-43890

BEARING

28

706-73-05030

SPACER KIT

|28

SPACER¤ 2.1MM

|28

SPACER¤ 2.4MM

|28

SPACER¤ 2.7MM

29

04064-03515

RING,SNAP

30

708-7T-12230

SEAL

31

04065-04518

RING,SNAP

32

706-73-43190

BLOCK,CYLINDER

33

706-73-43742

PLATE,VALVE

34

720-68-19610

PIN

35

706-73-43120

SHAFT,CENTER

36

706-73-43130

RING,CENTER

37

706-73-41110

SPRING

|38

706-73-05020

RETAINER KIT

38

RETAINER

39

SCREW

40

706-73-43160

PISTON SUB ASS'Y

41

706-73-92340

PLATE

42

706-73-92350

DISK

43

706-73-92380

PISTON,BRAKE

44

706-73-92390

RING,BRAKE

45

07000-12115

O-RING

46

07000-12130

O-RING

47

708-7T-15150

SPRING
