Запчасти Komatsu PC128UU-2 ЦИЛИНДР СТРЕЛЫ(ВНУТР. ЧАСТИ) (РУКОЯТЬ CRANE СПЕЦ-Я.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XF330

BOOM CYLINDER GROUP,L.H.

|G1

707-01-XF340

BOOM CYLINDER GROUP,R.H.

|1

21Y-63-02700

CYLINDER ASS'Y

1

21Y-63-52340

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-27-10971

HEAD,CYLINDER

6

707-52-90470

BUSHING

7

707-51-70030

PACKING,ROD (KIT)

8

707-51-70630

RING,BUFFER (KIT)

9

07000-15095

O-RING (KIT)

10

707-35-91060

RING,BACK-UP (KIT)

11

144-63-95170

SEAL,DUST (KIT)

12

07179-12084

RING,SNAP

13

707-88-22290

BRACKET

14

01010-81465

BOLT

15

705-17-04980

WASHER

16

21Y-63-52520

ROD

17

707-76-70230

BUSHING

18

07145-00070

SEAL,DUST (KIT)

19

707-36-10571

PISTON

20

707-44-10280

RING,PISTON (KIT)

21

707-39-10520

RING,WEAR (KIT)

22

707-44-10911

RING

23

01310-01216

SCREW

24

707-34-60030

O-RING (KIT)

25

707-35-90730

RING,BACK-UP (KIT)

26

21Y-63-52570

TUBE,L.H.

|26

21Y-63-52670

TUBE,R.H.

27

07000-13025

O-RING (KIT)

28

01010-80850

BOLT

29

01643-50823

WASHER

30

707-88-96971

BAND

31

21Y-63-52590

BRACKET

32

01010-81035

BOLT

33

01643-51032

WASHER

34

01010-81030

BOLT

35

01643-31032

WASHER

K

707-98-37670

SERVICE KIT,BOOM CYLINDER
