Запчасти Komatsu PC128UU-2 СТРЕЛА (HYDRAURIC ЛИНИЯ И РАБОЧ. ОСВЕЩЕНИЕ) (BLUE) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21Y-62-21910

HOSE

2

21Y-62-21920

HOSE

3

21Y-62-21931

HOSE

|3

21Y-62-21930

HOSE

4

21Y-62-21941

HOSE

|4

21Y-62-21940

HOSE

5

21Y-62-21950

HOSE

6

21Y-62-21960

HOSE

7

21Y-70-21270

COVER

8

01010-81020

BOLT

9

103-54-21160

COLLAR

10

21Y-70-23170SS

CLAMP

|10

21Y-70-14271SS

CLAMP

11

21Y-70-23180SS

CLAMP

|11

21Y-70-14281SS

CLAMP

12

21Y-70-23190SS

CLAMP

|12

21Y-70-14291SS

CLAMP

13

01011-81010

BOLT

13A

01643-31032

WASHER

14

01010-81030

BOLT

15

01643-31032

WASHER

|15

01643-31032

WASHER

16

07095-00421

CUSHION

17

07094-00417

CLAMP

18

01010-81240

BOLT

19

01643-31232

WASHER

20

427-03-10350SS

PLATE

21

01010-81235

BOLT

22

01643-31232

WASHER

23

21Y-70-23210

CUSHION

|23

21Y-70-14331

CUSHION

24

08034-20834

BAND

24A

21W-70-46940

PIN

24B

04205-11035

PIN

25

22B-06-11690

WORK LAMP ASS'Y

|25

20Y-06-21480

WORK LAMP ASS'Y

26

21Y-70-21350

BRACKET

|26

21Y-70-14550NU

BRACKET

27

21W-70-21270NU

COVER

28

01010-81030

BOLT

28A

01643-31032

WASHER

29

01010-81035

BOLT

30

01643-31032

WASHER

|30

01643-31032

WASHER

31

20T-70-71630

PAD

32

20T-70-71640

COLLAR

33

01010-80816

BOLT

34

01643-30823

WASHER
