Запчасти Komatsu PC128UU-2 СТРЕЛА (HYDRAURIC ЛИНИЯ И СМАЗЫВАЮЩ. ЛИНИЯ) (BLUE) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

22B-70-15220SS

PIN

2

20U-70-31340

SPACER¤ 1.0MM

3

20U-70-31330

SPACER¤ 0.5MM

4

176-72-41230SS

PLATE

5

01010-81235

BOLT

6

01643-31232

WASHER

7

21Y-70-14121SS

PIN

8

176-72-41230SS

PLATE

9

01010-81235

BOLT

10

01643-31232

WASHER

11

21Y-70-14870

SHIM¤ 0.5MM

|11

21Y-70-14870

SHIM¤ 0.5MM

11A

21Y-70-14890

SPACER

12

202-70-61180

PIN

13

01019-11640

BOLT

14

01580-11613

NUT

15

21Y-70-14830

SPACER¤ 1.0MM

16

21K-70-11410SS

PLATE (BLUE)

17

21Y-70-14150SS

PIN

18

176-72-41230SS

PLATE

18A

21Y-70-21320SS

PLATE

19

01010-81235

BOLT

20

01643-31232

WASHER

21

21Y-70-14860

SPACER¤ 1.5MM

|21

21Y-70-14860

SPACER¤ 1.5MM

22

07049-02430

PLUG

23

21Y-70-12250SS

PIN

24

176-72-41230SS

PLATE

25

01010-81235

BOLT

26

01643-31232

WASHER

27

21Y-70-14720

SPACER¤ 0.5MM

28

07049-01215

PLUG

29

21Y-70-14560SS

PIN

30

176-72-41230SS

PLATE

31

01010-81235

BOLT

32

01643-31232

WASHER

33

21Y-70-14770

SPACER¤ 1.0MM
