Запчасти Komatsu PC128UU-2 ОСНОВН. КОНСТРУКЦИЯ (КЛАПАН PPCAND ТРУБЫ ЛЕВ.) (ОБОГРЕВАТЕЛЬ.) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

702-16-01651

VALVE ASS'Y

1

702-16-01661

VALVE ASS'Y

2

01010-80820

BOLT

3

01643-30823

WASHER

4

08053-01510

CLIP

5

07230-20210

UNION

5

07230-20210

UNION

6

07002-11423

O-RING

6

07002-11423

O-RING

7

07236-10210

ELBOW

8

07002-11423

O-RING

9

22B-62-13270

HOSE, 3700MM,ORANGE

9

22B-62-13230

HOSE, 3550MM,ORANGE

9

21U-62-34740

BAND, ORANGE

10

22B-62-13480

HOSE, 3800MM,WHITE

10

22B-62-13230

HOSE, 3550MM,WHITE

10

21U-62-34770

BAND, WHITE

11

22B-62-13390

HOSE, 3650MM,BROWN

11

22B-62-13240

HOSE, 3450MM,BROWN

11

21U-62-34780

BAND, BROWN

12

22B-62-13390

HOSE, 3650MM,GREEN

12

22B-62-13240

HOSE, 3450MM,GREEN

12

21U-62-34730

BAND, GREEN

13

22B-62-13190

HOSE, 1950MM,RED-GREEN

13

22B-62-13250

HOSE, 1800MM,RED-GREEN

13

21U-62-34760

BAND, RED

13

21U-62-34730

BAND, GREEN

14

22B-62-13290

HOSE, 2300MM,BLUE-WHITE

14

22B-62-13261

HOSE, 2150MM,BLUE-WHITE

14

21U-62-34750

BAND, BLUE

14

21U-62-34770

BAND, WHITE

15

702-16-53240

PLUG

16

203-62-57730

BOLT

17

07000-12018

O-RING

18

08034-00536

BAND

19

113-899-7950

CLIP

20

01010-81020

BOLT

21

01643-31032

WASHER

22

201-54-74280

CONSOLE BOX

22

201-54-73281

CONSOLE BOX

23

20T-54-71570

BOLT

24

20T-54-71550

BOLT

25

01643-70823

WASHER

26

201-06-71210

SWITCH

27

201-54-73190

SPACER

28

20Y-06-23421

SWITCH

29

20Y-06-23950

SWITCH

30

201-54-73410

COVER

31

201-54-73291

COVER

32

22U-54-15610

COVER

33

22U-00-11330

PLATE,PANEL

34

7824-84-2810

SWITCH

34

7824-84-2890

KNOB

35

203-54-64220

PLATE

36

01010-80816

BOLT

37

01643-30823

WASHER

38

201-54-73410

COVER
