Запчасти Komatsu PC128UU-2 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XM860

CYLINDER GROUP,(FINAL COATING)

G1

21Y-63-X9130

CYLINDER GROUP,BUCKET (NATURAL YELLOW)

|$3

21Y-63-02730

CYLINDER ASS'Y,BUCKET

1

202-63-75140

CYLINDER,BUCKET

2

707-76-65210

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

07020-00900

FITTING,GREASE

5

707-27-90920

HEAD,CYLINDER

6

707-52-90360

BUSHING

7

707-51-60030

PACKING,ROD (KIT)

8

707-51-60630

RING,BUFFER (KIT)

9

07000-15080

O-RING (KIT)

10

707-35-90980

RING,BACK-UP (KIT)

11

141-63-93270

SEAL,DUST (KIT)

12

07179-12074

RING,SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

202-63-75120

ROD

16

707-76-65220

BUSHING

17

707-77-65110

SEAL,DUST (KIT)

18

07020-00900

FITTING,GREASE

19

707-36-90350

PISTON

20

707-44-90180

RING,PISTON (KIT)

21

707-39-90110

RING,WEAR (KIT)

22

707-44-90911

RING

23

01310-01016

SCREW,NYLON

24

07000-15055

O-RING (KIT)

25

707-35-90920

RING,BACK-UP (KIT)

26

21Y-63-72470

TUBE

27

21Y-63-72181

TUBE

28

07000-13025

O-RING (KIT)

29

01010-80850

BOLT

30

01643-50823

WASHER

31

707-88-96280

BAND

32

707-88-95523

BRACKET

33

707-88-96280

BAND

34

21Y-63-72191

BRACKET

35

01010-81035

BOLT

36

01643-51032

WASHER

37

07283-22236

CLIP

38

01599-01011

NUT

39

01643-31032

WASHER

K

707-98-27620

SERVICE KIT,BUCKET CYLINDER
