Запчасти Komatsu PC128UU-2 ЦИЛИНДР СТРЕЛЫ(ВНУТР. ЧАСТИ)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

707-01-XM830

CYLINDER GROUP,L.H. (FINAL COATING)

|$1

707-01-XM840

CYLINDER GROUP,R.H. (FINAL COATING)

|$2

21Y-63-X9100

CYLINDER ASS'Y,L.H. (NATURAL YELLOW)

|$3

21Y-63-X9110

CYLINDER ASS'Y,R.H. (NATURAL YELLOW)

|$5

21Y-63-02700

CYLINDER ASS'Y

1

21Y-63-52340

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-27-10971

HEAD,CYLINDER

6

707-52-90470

BUSHING

7

707-51-70030

PACKING,ROD (KIT)

8

707-51-70630

RING,BUFFER (KIT)

9

07000-15095

O-RING (KIT)

10

707-35-91060

RING,BACK-UP (KIT)

11

144-63-95170

SEAL,DUST (KIT)

12

07179-12084

RING,SNAP

13

707-88-22290

BRACKET

14

01010-81465

BOLT

15

705-17-04980

WASHER

16

21Y-63-52520

ROD

17

707-76-70230

BUSHING

18

07145-00070

SEAL,DUST (KIT)

19

707-36-10571

PISTON

20

707-44-10280

RING,PISTON (KIT)

21

707-39-10520

RING,WEAR (KIT)

22

707-44-10911

RING

23

01310-01216

SCREW

24

707-34-60030

O-RING (KIT)

25

707-35-90730

RING,BACK-UP (KIT)

26

21Y-63-52570

TUBE,L.H.

26

21Y-63-52670

TUBE,R.H.

27

21Y-63-52182

TUBE,L.H.

27

21Y-63-52282

TUBE,R.H.

28

07000-13025

O-RING (KIT)

29

01010-80850

BOLT

30

01643-50823

WASHER

31

707-88-96971

BAND

32

21Y-63-52590

BRACKET

33

01010-81035

BOLT

34

01643-51032

WASHER

35

01010-81030

BOLT

36

01643-31032

WASHER

K

707-98-37670

SERVICE KIT,BOOM CYLINDER
