Запчасти Komatsu PC128UU-2 МАРКИРОВКА (СЕВ. АМЕРИКА СПЕЦ-Я.) МАРКИРОВКА

1

09801-03001

PLATE, SAFETY,HAZARD0US VOLTAGE WARNING

2

09651-03001

PLATE, SAFETY,READ OPERATION MANUAL

3

09654-03001

PLATE, SAFETY,LOCK THE SAFETY LOCK LEVER

4

09803-03000

PLATE, SAFETY,WHEN OPENING WINDOW, LOCK IT

5

09802-03000

PLATE, SAFETY,WARNING OF MOVING MACHINE

6

09963-03001

TAG,DO NOT OPERATE

7

22B-00-11320

PLATE,SWING PARKING BRAKE RELEASE

8

22B-00-11310

PLATE,EMERGENCY PUMP DRIVE SWITCH

9

21W-98-21521

PLATE, OPERATING,EMERGENCY WORK EQUIPMENT S/W

10

20U-98-21910

PLATE, CAUTION,IF WINDOW IS BROKEN OR BECOMES

11

09822-03000

PLATE, SAFETY,OPERATING PATTERN TABLE (JIS)

12

09839-03000

PLATE, SAFETY,LOCK LEVER

13

21Y-00-21220

PLATE,FUSE

14

09685-00001

PLATE, OPERATING,SAFETY LOCK LEVER

15

21Y-98-17470

PLATE,DECEL SWITCH

16

362-54-38150

PLATE, OPERATING,STARTER SWITCH

17

21Y-98-17450

PLATE, OPERATING,LEVER OPERATING PATTERN

18

21W-98-21420

PLATE, CAUTION,INTERFERENCE PREVENT

19

21W-98-21430

PLATE, CAUTION,WORK EQUIPMENT AUTOMATIC CONT.

20

22U-54-16420

SHEET,RUBBER

21

22U-54-16430

SHEET,RUBBER

22

21Y-00-21121

OIL CHART

22

21Y-00-21160

PLATE,LUBRICATION STANDARD CHART

23

09133-23000

PLATE, SAFETY,KEEP OUT SWING AREA

24

09653-03001

PLATE, SAFETY,HYDRAULIC OIL INLET

25

09668-03001

PLATE, SAFETY,RADIATOR CAP

26

09669-0000E

PLATE, CAUTION,FUEL INLET

26

09669-0000B

PLATE, CAUTION,FUEL INLET

27

04418-13060

SCREW

28

09601-10000

PLATE, NAME,MODEL NAME

28

09601-00835

PLATE, NAME

28

09601-10000

PLATE, NAME,MODEL NAME

29

09659-53000

PLATE, SAFETY,ACCUMULATOR WARNING

30

203-00-31120

PLATE, INSTRUCTION,HYDRAULIC OIL GAUGE

31

21U-98-31160

PLATE, MARK,CENTER OF GRAVITY

32

21U-98-31150

PLATE, MARK,SLING POSITION

33

21Y-00-21170

PLATE,ILLUSTRATION OF SLINGING

34

09637-30163

PLATE, INSTRUCTION,AIR CLEANER ELEMENT MAINTE.

35

09667-03001

PLATE, SAFETY,REVOLVING OBJECT CAUTION

36

09805-13000

PLATE, SAFETY,DO NOT STEP ON HOOD

37

09805-03000

PLATE, SAFETY,DO NOT STEP ON COUNTER WEIGHT

38

09808-03000

PLATE, SAFETY,ELECTRIC SHOCK

39

09664-30082

PLATE, SAFETY,EXPLOSION OR BURNING

40

22A-00-11180

PLATE, INSTRUCTION,BATTERY CAUTION

41

09657-03003

PLATE, SAFETY,ADJUSTING TRACK TENSION

41A

22B-00-11340

PLATE, MARK,WASHER TANK

42

154-54-23260

SEAT,ANTI-SLIP

43

22B-00-11210

SHEET,ANTI-SLIP

44

22B-00-11220

SHEET,ANTI-SLIP

45

21Y-00-21190

MARK,MODEL LOGO

46

21Y-00-21210

MARK,MODEL LOGO

47

09690-F0710

PLATE, MARK,KOMATSU LOGO

48

09690-B0500

PLATE, MARK,KOMATSU LOGO

49

09690-B0800

PLATE, MARK,KOMATSU LOGO

50

09690-M0063

PLATE, MARK,KOMATSU LOGO

51

09690-F0315

PLATE, MARK,KOMATSU LOGO
