Запчасти Komatsu PC128UU-2 БОКОВ. КРЫШКА ЛЕВ. (ДЕКА КРЫШКАAND ОМЫВАТЕЛЬ БАК) (YELНИЗ.) ЧАСТИ КОРПУСА

1

22B-54-11713NK

COVER (YELLOW)

1

22B-54-11712NK

COVER (YELLOW)

2

22B-54-11742

PLATE

2

22B-54-11742NK

COVER (YELLOW),L.H.

3

22B-54-12660

SHIM

4

01010-81225

BOLT

5

01643-31232

WASHER

6

22B-54-11881

PLATE

6

22B-54-11881NK

PLATE (YELLOW)

7

205-54-51970

DOVE TAIL

8

01010-80616

BOLT

9

01643-30623

WASHER

10

01010-81225

BOLT

11

01643-31232

WASHER

12

22B-54-12890

SEAL

13

22B-54-11731

BRACKET

13

22B-54-11731NK

BRACKET (YELLOW)

14

01010-81225

BOLT

15

01643-31232

WASHER

16

22B-54-19290NK

COVER

16

22B-54-11721NK

COVER

17

203-54-62180

HINGE (WELDED)

18

198-54-41982

LOCK ASS'Y (WELDED)

18

421-54-11372

LOCK ASS'Y (WELDED)

19

421-54-11381

LOCK

20

20Y-54-29232

BAR

21

20R-54-11460

SPRING

22

01235-40516

SCREW

23

01601-20513

WASHER

24

205-54-53550

DOVE TAIL

25

01010-80616

BOLT

26

01643-30623

WASHER

27

203-54-62190NK

PLATE (YELLOW)

28

01010-81235

BOLT

29

01643-31232

WASHER

30

01010-81240

BOLT

31

01643-31232

WASHER

32

22B-54-11981NK

COVER (YELLOW)

33

01010-81240

BOLT

34

01643-31232

WASHER

35

22B-54-13830

TANK ASS'Y,(SEE FIG. K0350-01B0A)

35

22B-54-13830

TANK ASS'Y

35

21T-06-11350

WASHER TANK ASS'Y

35

22B-54-13840

CAP

36

01010-80616

BOLT

37

01643-30623

WASHER

38

22B-54-11772SG

BRACKET

39

01010-81230

BOLT

40

01643-31232

WASHER
