Запчасти Komatsu PC128UU-1 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21Y-60-12101

TRAVEL MOTOR ASS'Y

|1

TZ263B200002BQ

HYDRAULIC MOTOR A.

1

TZ263B210101-1

FLANGE KIT,REAR

2

TZGM1-8

PLUG

3

TZGDL1-16

PLUG

4

TZ121F2070-00

ORIFICE

5

GPF1-4

PLUG

6

TZ850A0006-00

PLATE¤ NAME

7

04260-00952

BALL

8

TZ263B2105-00

PISTON KIT (9 PIECES)

9

TZ263B2004-04

BLOCK,CYLINDER

10

TZ263B200301-B

PLATE,SWASH

11

TZ263B2007-01

PLATE,RETAINER

12

TZ263B2008-00

BOWL,THRUST

13

TZJB150625-238

PIN

14

TZ880A2010-00

WASHER

15

TZ263B2093-01

SPRING

16

TZTH-R-42

RING,SNAP

17

TZ263B2070-00

PISTON

18

TZ263B2074-00

PLATE

19

TZ800A2015-00

PLATE

20

TZ800A2016-00

PLATE

21

TZ263B2012-00

PISTON

22

TZ800A2013-00

SPRING

23

TZJW1516-G28-9

O-RING (K1)

24

TZSUN-3WG28

RING,BACK-UP (K1)

25

TZJW1516-G35-9

O-RING (K1)

26

TZSUN-3WG35

RING,BACK-UP (K1)

27

TZ263B2002-01

SHAFT

28

TZ263B2076-02

PIVOT

29

TZ263B2077-01

PIN

30

TZ263B2014-00

COLLAR

31

TZ263B2048-00

BEARING

32

TZ15Z-22-42-10

SEAL,OIL (K1)

33

TZ263A2009-01

PLATE,TIMING

34

TZJB1354-4-10

PIN

35

TZ263B2049-00

BEARING

36

TZ200B2073-00

VALVE

37

TZ300B2043-01

SPRING

38

TZ300B2039-00

STOPPER

39

TZ300B2042-00

RING

40

TZ263B2090-00

SPRING
