Запчасти Komatsu PC128UU-1 МОТОР ПОВОРОТА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC128UU-1 - МОТОР ПОВОРОТА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
22
23
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37
38
38
39
39
40
40
41
41
42
42
43
44

Артикул

Название

Примечание

Количество

|1

706-73-01130

SWING MOTOR ASS'Y

1

706-73-72560

HOUSING

2

706-73-43011

CASE

3

706-73-92160

SPRING

4

706-74-40320

BOLT

5

195-30-33190

O-RING

6

706-73-41091

BLOCK,CYLINDER

7

706-73-42740

PLATE,VALVE

8

04020-00616

PIN,DOWEL

9

706-73-41164

PISTON ASS'Y

10

706-73-42180

SHAFT,CENTER

11

706-73-41220

BALL,CENTER

12

706-73-41110

SPRING

13

706-73-41130

RING,CENTER

14

706-73-40010

BEARING

15

706-73-43860

SHAFT,DRIVE

16

706-73-42260

RETAINER

17

706-73-42270

SCREW

18

706-73-92180

PISTON,BRAKE

19

07000-12130

O-RING

20

07000-12145

O-RING

21

706-73-42820

PIN,DOWEL

22

706-73-92140

PLATE

23

706-75-90050

DISK

24

706-73-92130

PLATE

25

706-74-41880

BEARING

26

706-75-40890

BEARING

27

706-73-42610

SPRING

28

706-73-42620

SEAT

29

706-73-05010

SPACER KIT

|29

SPACER¤ 3.0MM

|29

SPACER¤ 3.4MM

|29

SPACER¤ 3.8MM

30

04064-04018

RING,SNAP

31

706-73-42711

COVER

32

708-8D-12210

SEAL,OIL

33

07000-02080

O-RING

34

04065-08530

RING,SNAP

35

706-77-72280

PLUG

36

07002-12034

O-RING

37

706-77-72170

PLUG

38

07002-12434

O-RING

39

706-73-72420

VALVE

40

706-73-72440

SPRING

41

706-73-72430

PLUG

42

07002-12434

O-RING

43

21Y-60-12210

VALVE ASS'Y

44

21Y-60-12220

VALVE ASS'Y

Выбрано товаров: 48
