Запчасти Komatsu PC128UU-1 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21Y-63-X2131

CYLINDER GROUP,BUCKET

|1

21Y-63-02131

CYLINDER ASS'Y,BUCKET

1

202-63-74541

CYLINDER,BUCKET

2

707-76-65210

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

07020-00900

FITTING,GREASE

5

707-27-90620

HEAD,CYLINDER

6

707-52-90350

BUSHING

7

707-51-60030

PACKING,ROD (KIT)

8

707-51-60630

RING,BUFFER (KIT)

9

07000-15085

O-RING (KIT)

10

707-35-90960

RING,BACK-UP (KIT)

11

141-63-93270

SEAL,DUST (KIT)

12

07179-12074

RING,SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

202-63-74320

ROD

16

707-76-65220

BUSHING

17

707-77-65110

SEAL,DUST (KIT)

18

07020-00900

FITTING,GREASE

19

707-36-90300

PISTON

20

707-44-90180

RING,PISTON (KIT)

21

707-39-90110

RING,WEAR (KIT)

22

707-44-90911

RING

23

07165-14244

NUT,NYLON

24

21Y-63-72171

TUBE

25

21Y-63-72181

TUBE

26

07000-13025

O-RING (KIT)

27

01010-50850

BOLT

28

01643-50823

WASHER

29

707-88-96280

BAND

30

707-88-95522

BRACKET

31

707-88-96280

BAND

32

21Y-63-72191

BRACKET

33

01010-51035

BOLT

34

01643-51032

WASHER

35

07283-22236

CLIP

36

01599-01011

NUT

37

01643-31032

WASHER
