Запчасти Komatsu PC128UU-1 ЦИЛИНДР СТРЕЛЫ(ВНУТР. ЧАСТИ) (ДЛЯ MONO-СТРЕЛА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21Y-63-X2102

CYLINDER GROUP,BOOM¤ L.H.

G2

21Y-63-X2112

CYLINDER GROUP,BOOM¤ R.H.

|1

21Y-63-02101

CYLINDER ASS'Y,BOOM

1

21Y-63-52141

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-27-10670

HEAD,CYLINDER

6

707-52-90450

BUSHING

7

707-51-70030

PACKING,ROD (KIT)

8

707-51-70630

RING,BUFFER (KIT)

9

07000-15100

O-RING (KIT)

10

07001-05100

RING,BACK-UP (KIT)

11

144-63-95170

SEAL,DUST (KIT)

12

07179-12084

RING,SNAP

13

707-88-83130

BRACKET

14

01010-81465

BOLT

15

705-17-04980

WASHER

16

21Y-63-52121

ROD

17

707-76-70230

BUSHING

18

07145-00070

SEAL,DUST (KIT)

19

707-36-10510

PISTON

20

707-44-10280

RING,PISTON (KIT)

21

707-39-10520

RING,WEAR (KIT)

22

707-44-10911

RING

23

07165-15252

NUT,NYLON

24

21Y-63-52172

TUBE,L.H.

|24

21Y-63-52272

TUBE,R.H.

25

21Y-63-52182

TUBE,L.H.

|25

21Y-63-52282

TUBE,R.H.

26

07000-13025

O-RING (KIT)

27

01010-50850

BOLT

28

01643-50823

WASHER

29

707-88-96971

BAND

30

21Y-63-52192

BRACKET

31

01010-51035

BOLT

32

01643-51032

WASHER

33

01010-51030

BOLT

34

01643-31032

WASHER
