Запчасти Komatsu PC128UU-1 ТОПЛИВН. БАК. (БАК) ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

21Y-04-11111

TANK

2

22U-04-11750

FLANGE

|2

21W-04-21121

FLANGE

3

01220-40635

SCREW

|3

01220-40630

SCREW

4

01602-20619

WASHER,SPRING

5

07000-12020

O-RING

|5

07000-02015

O-RING

6

20U-04-21431

FLANGE

|6

21Y-04-11130

FLANGE

7

07700-50455

VALVE

|7

20Y-04-11130

VALVE

8

01220-40620

SCREW

9

01602-20619

WASHER,SPRING

10

07000-02018

O-RING

|10

07000-02015

O-RING

11

20B-04-21110

NIPPLE

12

21T-03-71270

ELBOW

|12

20G-68-12930

ELBOW

13

21Y-04-11381

FLANGE ASS'Y

|13

21Y-04-11380

FLANGE ASS'Y

14

01220-40616

SCREW

15

01602-20619

WASHER,SPRING

16

07000-02015

O-RING

16A

21Y-04-11390

SHEET

17

21Y-06-17120

SENSOR,FUEL

|17

7861-92-5820

SENSOR,FUEL

18

01252-40612

BOLT

19

01602-20619

WASHER,SPRING

20

07000-03048

O-RING

21

21Y-04-18100

VALVE ASS'Y

22

21Y-04-18150

SPACER

23

07000-12015

O-RING

24

07000-12014

O-RING

25

01010-80645

BOLT

26

01643-30623

WASHER

27

07288-01006

HOSE

|27

07288-01001

HOSE

28

198-09-31210

CLAMP

|28

07281-00197

CLAMP
