Запчасти Komatsu PC128UU-1 КАБИНА (/7) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu PC128UU-1 - КАБИНА (/7) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
2
3
4
5
6
7
8
9
9
9
9A
10
11
12
13
14
15
16
17
18
19
19
20
21
22
23
24
25
25
26
27
28
28
29
30
31
32
33
34

Артикул

Название

Примечание

Количество

|1

21W-54-00057

CAB ASS'Y

|1

21W-54-00056

CAB ASS'Y

|1

21W-54-00055

CAB ASS'Y

|1

21W-54-00054

CAB ASS'Y

|1

21W-54-00053

CAB ASS'Y

|1

21W-54-00076

CAB ASS'Y,(WITH FRONT GUARD)

|1

21W-54-00075

CAB ASS'Y,(WITH FRONT GUARD)

|1

21W-54-00074

CAB ASS'Y,(WITH FRONT GUARD)

|1

21W-54-00073

CAB ASS'Y,(WITH FRONT GUARD)

|1

21W-54-00072

CAB ASS'Y,(WITH FRONT GUARD)

|1

21W-54-00091

CAB ASS'Y,(WITH HEAD GUARD)

|1

21W-54-00090

CAB ASS'Y,(WITH HEAD GUARD)

1

CAB

|1

CAB

|1

CAB

|1

CAB,(WITH FRONT GUARD)

|1

CAB,(WITH FRONT GUARD)

|1

CAB,(WITH HEAD GUARD)

|1

CAB,(WITH HEAD GUARD)

2

20T-54-84750

WINDOW,L.H.¤ UPPER

|2

20U-54-24752

WINDOW,L.H.¤ UPPER

3

20U-54-24971

DAM,L.H.¤ UPPER

4

20U-54-25151

TRIM

5

20T-54-84760

WINDOW,L.H.¤ LOWER

|5

20U-54-24761

WINDOW,L.H.¤ LOWER

6

20U-54-24981

DAM,L.H.¤ LOWER

7

21W-54-34770

WINDOW,REAR

|7

20U-54-24772

WINDOW,REAR

8

20U-54-24991

DAM

9

20U-54-25161

TRIM

|9

20U-54-25161

TRIM

9A

20U-54-25162

SEAL

10

20U-54-24861

LINING,REAR

|10

20U-54-24860

LINING,REAR

11

20U-54-24871

LINING,L.H.

12

20U-54-24881

LINING,R.H.

13

20U-54-25541

COVER,REAR

|13

20U-54-25540

COVER,REAR

14

20U-54-25170

SEAL

15

20T-54-75121

DUCT

|15

20T-54-75120

DUCT

16

21W-54-14690

CLIP

|16

21W-54-14690

CLIP

17

20U-54-24681

TAPE

18

20U-54-25510

SEAL

19

20U-54-25140

STOPPER

20

20T-54-84960

SHEET

|20

20U-54-25530

SHEET

21

20U-54-24711

GLASS

22

20U-54-24721

STRIP,WEATHER

23

20U-54-24733

WINDOW,UPPER

|23

20U-54-24732

WINDOW,UPPER

24

20U-54-24741

STRIP,WEATHER

25

20T-54-75210

GROMMET

26

08037-01008

GROMMET

27

08037-01610

GROMMET

28

09415-01008

CAP

|28

09415-01008

CAP

29

09415-00706

CAP

30

01220-40412

SCREW

31

01641-20405

WASHER

32

01220-40612

SCREW

33

01641-20608

WASHER

34

01370-00412

SCREW

Выбрано товаров: 64
