Артикул
Название
Примечание
Количество
|$3
723-38-13400
VALVE ASS'Y
|$4
723-38-13103
VALVE ASS'Y
|$5
723-38-13101
VALVE ASS'Y
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1664-21A0 TO Y1664-32A0.
|$7
BODY SUB ASS'Y
|$8
BODY SUB ASS'Y
|$9
BODY SUB ASS'Y
|$10
723-30-66100
VALVE ASS'Y
1
PLUG
2
SEAT
3
BALL
4
07002-12434
O-RING
5
07000-12012
O-RING
6
07001-02012
RING,BACK-UP
7
07000-12010
O-RING
8
07001-02010
RING
|$19
723-30-66200
VALVE ASS'Y
9
PLUG
10
SEAT
11
BALL
12
07002-12434
O-RING
13
07000-12012
O-RING
14
07001-02012
RING,BACK-UP
15
07000-12010
O-RING
16
07001-02010
RING
|$28
723-30-60101
VALVE ASS'Y
|$29
723-30-60100
VALVE ASS'Y
17
SLEEVE
18
VALVE
19
PISTON
19
PISTON
20
PISTON
21
SPRING
22
SPRING
23
PLUG
24
SEAL
24
SEAL
25
O-RING
26
O-RING
27
709-25-11390
O-RING
28
07000-12012
O-RING
29
07001-02012
RING,BACK-UP
Выбрано товаров: 42
