Запчасти Komatsu PC128UU-1 МОТОР ПОВОРОТА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC128UU-1 - МОТОР ПОВОРОТА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
28
29
30
30
31
32
33
34
35
36
37
38
39
40

Артикул

Название

Примечание

Количество

|$1

706-73-01130

SWING MOTOR ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 TO Y1640-03A0.

|$3

21Y-60-12220

VALVE ASS'Y,(MB)

|$$4

THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

1

BODY

2

PLUG

3

SEAT,VALVE

4

DISTANCE

5

O-RING

6

POPPET

7

SPRING

8

SCREW,ADJUST

9

NUT

10

SOLENOID

11

UC1301001004

O-RING

12

UC1301514005

BOLT

13

BODY

14

PLUNGER

15

SEAT,VALVE

16

GUIDE

17

O-RING

18

SEAT,SPRING

19

RING,BACK-UP

20

O-RING

21

SPRING

22

BOLT

23

SEAT,SPRING

24

SCREW

25

NUT

26

UC1100423151

NUT

27

07002-12434

O-RING

28

UC1303006937

RING,BACK-UP

29

UC1303026115

O-RING

30

UC1303006982

RING,BACK-UP

31

UC1301201002

O-RING

32

DISTANCE

33

PLUG

34

UC1301147009

O-RING

35

UC1100435989

FILTER

36

UC1198273704

PLUG

37

UC1301180006

O-RING

38

07040-11409

PLUG

39

07002-11423

O-RING

40

UC1303011957

BOLT

Выбрано товаров: 44
