Запчасти Komatsu PC128UU-1 МОТОР ПОВОРОТА (/)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

706-73-01200

SWING MOTOR ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0A AND Y1640-02A0 A.

|$4

706-73-03140

MOTOR SUB ASS'Y

1

706-73-43110

CASE,MOTOR

|$6

706-73-00020

HOUSING SUB ASS'Y

2

HOUSING

3

PLUG

4

706-73-40010

BEARING

5

706-73-42820

PIN

6

706-73-72680

PLUG

7

07002-11223

O-RING

|$13

706-73-72710

VALVE SUB ASS'Y

8

706-73-72720

VALVE

9

706-73-72730

POPPET

10

706-73-72740

PLUG

11

706-73-72440

SPRING

12

706-73-72750

PLUG

13

07000-12020

O-RING

14

07001-02020

RING,BACK-UP

15

706-73-72420

VALVE

16

706-73-72440

SPRING

17

706-73-72430

PLUG

18

07002-12434

O-RING

19

07000-02145

O-RING

20

01252-61240

BOLT

21

706-73-43960

SHAFT,DRIVE

22

706-73-43880

BEARING

23

706-73-43810

SPACER

24

706-73-43610

SPRING

25

706-73-43620

SEAT

26

706-73-43890

BEARING

27

706-73-05030

SPACER KIT

27

SPACER, 2.1MM

27

SPACER, 2.4MM

27

SPACER, 2.7MM

28

04064-03515

RING,SNAP

29

708-7T-12230

SEAL

30

04065-04518

RING,SNAP

31

706-73-43190

BLOCK,CYLINDER

32

706-73-43742

PLATE,VALVE

33

720-68-19610

PIN

34

706-73-43120

SHAFT,CENTER

35

706-73-43130

RING,CENTER

36

706-73-41110

SPRING

|$46

706-73-05020

RETAINER KIT

37

706-73-42260

RETAINER

38

706-73-42270

SCREW

39

706-73-43160

PISTON SUB ASS'Y

40

706-73-92340

PLATE

41

706-73-92350

DISK

42

706-73-92380

PISTON,BRAKE

43

706-73-92390

RING,BRAKE

44

07000-12115

O-RING

45

07000-12130

O-RING

46

708-7T-15150

SPRING
