Артикул
Название
Примечание
Количество
|$1
706-73-01130
SWING MOTOR ASS'Y
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 TO Y1640-03A0.
1
706-73-72560
HOUSING
2
706-73-43011
CASE
3
706-73-92160
SPRING
4
706-74-40320
BOLT
5
195-30-33190
O-RING
6
706-73-41091
BLOCK,CYLINDER
7
706-73-42740
PLATE,VALVE
8
04020-00616
PIN,DOWEL
9
706-73-41164
PISTON ASS'Y
10
706-73-42180
SHAFT,CENTER
11
706-73-41220
BALL,CENTER
12
706-73-41110
SPRING
13
706-73-41130
RING,CENTER
14
706-73-40010
BEARING
15
706-73-43860
SHAFT,DRIVE
16
706-73-42260
RETAINER
17
706-73-42270
SCREW
18
706-73-92180
PISTON,BRAKE
19
07000-12130
O-RING
20
07000-12145
O-RING
21
706-73-42820
PIN,DOWEL
22
706-73-92140
PLATE
23
706-75-90050
DISK
24
706-73-92130
PLATE
25
706-74-41880
BEARING
26
706-75-40890
BEARING
27
706-73-42610
SPRING
28
706-73-42620
SEAT
29
706-73-05010
SPACER KIT
29
SPACER, 3.0MM
29
SPACER, 3.4MM
29
SPACER, 3.8MM
30
04064-04018
RING,SNAP
31
706-73-42711
COVER
32
708-8D-12210
SEAL,OIL
33
07000-02080
O-RING
34
04065-08530
RING,SNAP
35
706-77-72280
PLUG
36
07002-12034
O-RING
37
706-77-72170
PLUG
38
07002-12434
O-RING
39
706-73-72420
VALVE
40
706-73-72440
SPRING
41
706-73-72430
PLUG
42
07002-12434
O-RING
43
21Y-60-12210
VALVE ASS'Y
44
21Y-60-12220
VALVE ASS'Y
Выбрано товаров: 49
