Запчасти Komatsu PC128UU-1 ТОПЛИВН. БАК. (БАК) ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

21Y-04-11111

TANK

2

22U-04-11750

FLANGE

2

21W-04-21121

FLANGE

3

01220-40635

SCREW

3

01220-40630

SCREW

4

01602-20619

WASHER,SPRING

5

07000-12020

O-RING

5

07000-02015

O-RING

6

20U-04-21431

FLANGE

6

21Y-04-11130

FLANGE

7

07700-50455

VALVE

7

20Y-04-11130

VALVE

8

01220-40620

SCREW

9

01602-20619

WASHER,SPRING

10

07000-02018

O-RING

10

07000-02015

O-RING

11

20B-04-21110

NIPPLE

12

21T-03-71270

ELBOW

12

20G-68-12930

ELBOW

13

21Y-04-11381

FLANGE ASS'Y

13

21Y-04-11380

FLANGE ASS'Y

14

01220-40616

SCREW

15

01602-20619

WASHER,SPRING

16

07000-02015

O-RING

17

21Y-04-11390

SHEET (BONDED)

18

7861-92-5820

SENSOR,FUEL

19

01252-40612

BOLT

20

01602-20619

WASHER,SPRING

21

07000-03048

O-RING

22

21Y-04-18100

VALVE ASS'Y

23

21Y-04-18150

SPACER

24

07000-02015

O-RING

25

01010-80645

BOLT

26

01643-30623

WASHER

27

07288-01001

HOSE

27

07288-01006

HOSE

28

198-09-31210

CLAMP

28

07281-00197

CLAMP
