Запчасти Komatsu PC128US-2 МАРКИРОВКА (СЕВ. АМЕРИКА СПЕЦ-Я.) (ДЛЯ ОТВАЛ)(№-77) МАРКИРОВКА

1

09801-03001

PLATE, SAFETY,HAZARDOUS VOLTAGE HAZARD

2

09651-03001

PLATE, SAFETY,READ OPERATION MANUAL

3

09654-03001

PLATE, SAFETY,LOCK THE SAFETY LOCK LEVER

4

09803-03000

PLATE, SAFETY,WHEN OPENING WINDOW, LOCK IT

5

09802-03000

PLATE, SAFETY,WARNING OF MOVING MACHINE

6

09963-03001

TAG,DO NOT OPERATE

7

22B-00-11320

PLATE,SWING PARKING BRAKE RELEASE

8

22B-00-11310

PLATE,EMERGENCY PUMP DRIVE SWITCH

9

20U-98-21910

PLATE, CAUTION,IF WINDOW IS BROKEN OR BECOMES

10

09822-03000

PLATE, SAFETY,OPERATING PATTERN TABLE (JIS)

11

09839-03000

PLATE, SAFETY,FRONT WINDOW OPEN

12

22B-00-11290

PLATE,FUSE

13

09685-00001

PLATE, OPERATING,SAFETY LOCK LEVER

14

21Y-98-17470

PLATE,DECEL SWITCH

15

362-54-38150

PLATE, OPERATING,STARTER SWITCH

16

201-00-61320

PLATE, OPERATING,BLADE LEVER OPERATING PATTERN

17

22U-54-16420

SHEET,RUBBER

18

22U-54-16430

SHEET,RUBBER

19

22B-00-11270

PLATE,LUBRICATION STANDARD CHART

20

09133-23000

PLATE, SAFETY,KEEP OUT SWING AREA

21

09653-03001

PLATE, SAFETY,HYDRAULIC OIL INLET

22

09668-03001

PLATE, SAFETY,RADIATOR CAP

23

09669-0000B

PLATE, CAUTION,FUEL INLET

24

04418-13060

SCREW

25

09601-00835

PLATE, NAME

25

09601-10000

PLATE, NAME,MODEL NAME

26

09659-53000

PLATE, SAFETY,ACCUMULATOR WARNING

27

203-00-31120

PLATE, INSTRUCTION,HYDRAULIC OIL GAUGE

28

21U-98-31160

PLATE, MARK,CENTER OF GRAVITY

29

21U-98-31150

PLATE, MARK,SLING POSITION

30

22B-00-11280

PLATE,ILLUSTRATION OF SLINGING

31

09637-30163

PLATE, INSTRUCTION,AIR CLEANER ELEMENT MAINTE.

32

09667-03001

PLATE, SAFETY,REVOLVING OBJECT CAUTION

33

09805-13000

PLATE, SAFETY,DO NOT STEP ON HOOD

34

09805-03000

PLATE, SAFETY,DO NOT STEP ON COUNTER WEIGHT

35

09808-03000

PLATE, SAFETY,ELECTRIC SHOCK

36

09664-30082

PLATE, SAFETY,EXPLOSION OR BURNING

37

22A-00-11180

PLATE, INSTRUCTION,BATTERY CAUTION

38

09657-03003

PLATE, SAFETY,ADJUSTING TRACK TENSION

38A

22B-00-11340

PLATE, MARK

39

154-54-23260

SEAT,ANTI-SLIP

40

22B-00-11210

SHEET,ANTI-SLIP

41

22B-00-11220

SHEET,ANTI-SLIP

42

22A-00-11130

MARK,MODEL LOGO

43

22A-00-11140

MARK,MODEL LOGO

44

09690-F0710

PLATE, MARK,KOMATSU LOGO

45

09690-B0800

PLATE, MARK,KOMATSU LOGO

46

09690-M0063

PLATE, MARK,KOMATSU LOGO

47

09690-F0315

PLATE, MARK,KOMATSU LOGO
