Запчасти Komatsu PC128US-2 ОСНОВН. КОНСТРУКЦИЯ (ОТВАЛ УПРАВЛ-Е)(№-77) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

201-910-7630

LEVER

2

203-43-44360

KNOB

3

01010-80816

BOLT

4

01643-30823

WASHER

5

203-43-61520

SEAT

6

01583-11408

NUT

7

702-16-01270

PILOT VALVE

8

01010-81020

BOLT

9

01643-31032

WASHER

10

20N-62-31250

NIPPLE

11

20U-62-22280

NIPPLE

12

20U-62-22430

ELBOW

13

21P-62-11590

ELBOW

14

07000-12011

O-RING

15

07184-00209

HOSE,RED-GREEN

16

07185-00211

HOSE,BLUE-WHITE

17

201-62-71360

HOSE, 2550MM,YELLOW-BLUE

18

22B-62-13341

HOSE, 2850MM,RED-BLACK

19

08034-00536

BAND

20

08036-03014

CLIP

|$38

20T-43-82311

PEDAL ASS'Y

21

20T-43-72320

BOOT

22

20T-43-72330

CAP

23

20T-43-72340

PEDAL

24

20T-43-82351

BODY

25

20T-43-82360

SHAFT

26

20T-43-72370

SPRING

27

20T-43-72380

WASHER

28

20T-06-71770

SWITCH

29

6134-71-5750

SCREW,CLIP

30

01641-20508

WASHER

31

20T-06-71781

HARNESS

32

203-54-32260

STOPPER

33

04025-00620

PIN

34

01010-81020

BOLT

35

01643-31032

WASHER
