Запчасти Komatsu PC128US-2 МАРКИРОВКА (ЯПОН.) (BLUE)(№7-8) МАРКИРОВКА

1

22A-00-11121

PLATE,SPECIFICATION

2

21W-98-41111

PLATE¤ CAUTION,ARARM ASS'Y PLATE

3

09803-A0480

PLATE¤ SAFETY,FRONT WINDOW OPEN

4

09963-00101

TAG,DO NOT OPERATE

5

22B-00-11370

PLATE¤ SAFETY,SWITCH

6

21U-98-21250

PLATE¤ CAUTION,IF WINDOW IS BROKEN OR BECOMES

7

21W-98-41340

PLATE¤ OPERATING,JIS PATTERN

8

22B-00-11171

PLATE,FUSE

9

22B-00-11153

PLATE,LUBRICATING STANDARD CHART

10

22U-00-21170

DECAL,LOCK FOR FRONT LOWER WINDOW

10A

22B-54-17650

PLATE,CABIN WITH HEAD GUARD

10B

21W-54-46350

SEAL

10C

09971-00100

PLATE,FREON COLLECT/DESTRUCTION LAW

11

09133-A2320

PLATE¤ SAFETY,KEEP OFF SWING AREA

12

09134-A1680

PLATE,KEEP OUT OF WORKING AREA

13

09653-A0480

PLATE¤ SAFETY,SAFETY

14

09669-0000B

PLATE¤ CAUTION,FUEL INLET

15

04418-13060

SCREW

16

09601-10000

PLATE¤ NAME,MACHINE MODEL

17

09659-A057A

PLATE¤ SAFETY,ACCUMULATOR WARNING

18

203-00-31120

PLATE¤ INSTRUCTION,HYDRAULIC OIL GAUGE

19

21U-98-31160

PLATE¤ MARK,ILLUSTRATION OF SLINGING

20

21U-98-31150

PLATE¤ MARK,SLING POSITION

21

22B-00-11160

PLATE¤ CAUTION,CENTER OF GRAVITY

22

09637-01163

PLATE¤ INSTRUCTION,AIR CLEANER ELEMENT MAINTE

23

09667-A0480

PLATE¤ SAFETY,REVOLUTION

24

09805-C0480

PLATE¤ SAFETY,DO NOT STEP ON HOOD

25

09805-A0480

PLATE¤ SAFETY,DO NOT STEP ON COUNTER WEIGHT

26

09808-A0880

PLATE¤ SAFETY,BATTERY CABLE

27

09657-A0880

PLATE¤ SAFETY,TRACK ADJUSTMENT

28

20U-98-22651

PLATE¤ CAUTION,BATTERY

29

22B-00-11340

PLATE¤ MARK,WASHER TANK

30

154-54-23260

SEAT,ANTI-SLIP

31

22B-00-11210

SHEET,ANTI-SLIP

32

22B-00-11220

PLATE¤ NAME,ANTI-SLIP

33

22A-00-11250

PLATE¤ MARK,MACHINE MODEL

34

09690-C1000

PLATE¤ MARK,KOMATSU

35

09690-M0063

PLATE¤ MARK,KOMATSU

36

09690-C0450

PLATE¤ MARK,KOMATSU

37

09690-F0315

PLATE¤ MARK,KOMATSU
