Запчасти Komatsu PC128US-2-AT ГИДРОЛИНИЯ РУКОЯТИ И КОВША(/) (ДЛЯ -НАВЕСН. ОБОРУД) ГИДРАВЛИКА

1

22B-62-19310

HOSE

|1

21U-62-34740

BAND¤ ORANGE

2

22B-62-19320

HOSE

|2

21U-62-34730

BAND¤ GREEN

3

22B-62-19330

HOSE

|3

21U-62-34760

BAND¤ RED

4

22B-62-19340

HOSE

|4

21U-62-34750

BAND¤ BLUE

5

08034-20834

BAND

6

22B-62-14221

CUSHION

7

22B-62-14231

CUSHION

8

22B-62-14242

CUSHION

9

22B-62-14252

CUSHION

10

22B-62-14262

CUSHION

11

22B-62-14580

BRACKET

12

01010-81235

BOLT

13

01643-31232

WASHER

14

22B-62-14590

BRACKET

15

01010-81220

BOLT

16

01643-31232

WASHER

17

01010-81020

BOLT

18

01643-31032

WASHER

19

22B-62-11320

PLATE

20

08034-20536

BAND

21

22B-62-17610

HOSE

|21

21U-62-34720

BAND¤ BLACK

|21

21U-62-34710

BAND¤ YELLOW

22

22B-62-17610

HOSE

|22

21U-62-34740

BAND¤ ORANGE

|22

21U-62-34710

BAND¤ YELLOW

23

22B-62-17620

HOSE

|23

21U-62-34730

BAND¤ GREEN

|23

21U-62-34710

BAND¤ YELLOW

24

22B-62-17630

HOSE

|24

21U-62-34780

BAND¤ BROWN

|24

21U-62-34710

BAND¤ YELLOW

25

22B-62-17650

HOSE

|25

21U-62-34780

BAND¤ BROWN

26

22B-62-17660

HOSE

|26

21U-62-34770

BAND¤ WHITE

27

22B-62-17670

HOSE

|27

21U-62-34720

BAND¤ BLACK

28

07095-01245

CUSHION

29

08034-20823

BAND
