Запчасти Komatsu PC128US-2-AC КАБИНА (ЗАМОК ДВЕРИ МЕХАНИЗМ) (С ДВЕРЬЮ РАМА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

22B-54-00551

CAB ASS'Y,WITH DOOR SASH

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-11A0.

|1

22B-54-00612

DOOR ASS'Y,WITH SASH WINDOW

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-05A2 TO K0210-07A2.

1

22B-54-16211

HANDLE

2

22B-54-16330

SNAP

3

01023-10612

SCREW

4

22B-54-16220

HANDLE

5

22B-54-16330

SNAP

6

22B-54-16370

SPACER

7

01023-10612

SCREW

8

22B-54-16231

BRACKET

9

22B-54-16590

SEAL

10

01023-20616

SCREW

11

22B-54-16200

LINK ASS'Y

12

01023-10612

SCREW

13

22B-54-16300

LINK ASS'Y

14

01023-10612

SCREW

15

22B-54-16380

LOCK ASS'Y

16

01240-00616

SCREW

17

195-Z11-1690

WASHER

18

22B-54-16390

LOCK ASS'Y

19

01240-00616

SCREW

20

195-Z11-1690

WASHER

21

20Y-54-35890

LOCK ASS'Y

22

205-54-71840

SNAP

23

22B-54-16441

COVER

24

22B-54-16461

RIVET

25

22B-54-16451

COVER

26

22B-54-16461

RIVET
