Запчасти Komatsu PC128US-2-AC СТРЕЛА (СТРЕЛА¤РАБОЧ. ОСВЕЩЕНИЕ И ПАЛЕЦ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

22B-70-00350

BOOM ASS'Y

1

BOOM ASS'Y

|2

22B-70-00220

BRACKET ASS'Y

2

BRACKET (WELDED)

3

203-46-41130

SEAT (WELDED)

4

21J-70-21310

BUSHING

5

22B-70-12230

SEAL

6

20T-54-74510

CAP

7

22B-70-12230

SEAL,DUST

8

22B-06-11690

WORK LAMP ASS'Y

9

421-06-23330

BULB¤ 70W

10

22B-70-11380

BRACKET

11

01010-81225

BOLT

12

01643-31232

WASHER

13

22B-06-11342

WIRING HARNESS

14

04434-51012

CLIP

15

08034-20834

BAND

16

08034-30521

BAND

17

01010-81020

BOLT

18

01643-31032

WASHER

19

22B-70-15220

PIN

20

21W-70-11310

PLATE

21

01010-81230

BOLT

22

01643-31232

WASHER

23

20U-70-31340

SPACER¤ 1.0MM

|23

20U-70-31330

SPACER¤ 0.5MM

24

203-70-42121

PIN

25

21W-70-11310

PLATE

26

01010-81230

BOLT

27

01643-31232

WASHER

28

21Y-70-14830

SPACER¤ 1.0MM

29

22B-62-19140

TUBE

30

02896-11018

O-RING

31

22B-62-19130

TUBE

32

02896-11015

O-RING

33

22B-62-19180

HOSE

34

22B-62-19190

HOSE

35

22B-62-19120

TUBE

36

02896-11012

O-RING

37

22B-62-19110

TUBE

38

02896-11015

O-RING
