Запчасти Komatsu PC128US-2-A КАБИНА (АКСЕССУАРЫ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

22B-54-00561

CAB ASS'Y

|1

22B-54-00551

CAB ASS'Y,WITH DOOR SASH

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-11A0.

1

22B-54-17312

COVER

2

20Y-54-18690

RIVET

3

22B-54-17331

COVER

4

20Y-54-18690

RIVET

5

205-54-51250

HANGER

6

01370-30412

SCREW

7

22B-54-17360

HOLDER

8

01370-40412

SCREW

9

22B-54-15591

COVER

10

01435-40616

BOLT

11

22B-54-16811

GRIP

12

01435-40820

BOLT

13

22B-54-16821

GRIP

14

01245-01030

SCREW

15

01643-71032

WASHER

16

22B-54-16831

GRIP

17

01245-01030

SCREW

18

01643-71032

WASHER

19

22B-54-17282

CAP

20

01245-01220

SCREW

21

01643-71232

WASHER

22

01245-00616

SCREW

23

01643-70623

WASHER

24

01245-01016

SCREW

25

01643-71032

WASHER

26

01245-00816

SCREW

27

01643-70823

WASHER

28

09415-02512

CAP

29

8A13-10-1310

ANTENNA

30

21W-54-43720

BRACKET

31

01010-D1220

BOLT

32

01643-71232

WASHER

33

20U-54-46520

STICKER

34

08034-40521

BAND

35

7836-10-2910

ANTENNA

36

7836-10-2920

CABLE

37

20Y-54-37150

SHEET

38

08034-20519

BAND
