Запчасти Komatsu PC128US-1 ЦИЛИНДР ОТВАЛА (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21Y-63-X2151

CYLINDER GROUP,BLADE LIFT¤ L.H.

G2

21Y-63-X2161

CYLINDER GROUP,BLADE LIFT¤ R.H.

|1

21Y-63-02151

CYLINDER ASS'Y,BLADE LIFT¤ L.H.

|1

21Y-63-02161

CYLINDER ASS'Y,BLADE LIFT¤ R.H.

1

21Y-63-92141

CYLINDER,BLADE LIFT¤ L.H.

|1

21Y-63-92241

CYLINDER,BLADE LIFT¤ R.H.

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (K4)

4

07020-00000

FITTING,GREASE

5

707-27-11670

HEAD,CYLINDER

6

707-52-90050

BUSHING

7

707-51-75030

PACKING,ROD (K4)

8

707-51-75630

RING,BUFFER (K4)

9

114-63-94170

SEAL,DUST (K4)

10

07179-13089

RING,SNAP

11

07000-15110

O-RING (K4)

12

07001-05110

RING,BACK-UP (K4)

13

707-88-83200

BRACKET

14

01010-81670

BOLT

15

01643-51645

WASHER

16

21Y-63-92121

ROD,PISTON

17

707-76-70230

BUSHING

18

07145-00070

SEAL,DUST (K4)

19

07020-00000

FITTING,GREASE

20

707-36-11540

PISTON

21

707-44-11280

RING,PISTON (K4)

22

707-39-11510

RING,WEAR (K4)

23

707-44-11920

RING

24

07165-13941

NUT

25

21Y-63-92171

TUBE,(L.H.)

|25

21Y-63-92271

TUBE,(R.H.)

26

21Y-63-92180

TUBE,(L.H.)

|26

21Y-63-92280

TUBE,(R.H.)

27

07000-13025

O-RING (K4)

28

01010-50850

BOLT

29

01643-50823

WASHER

30

21Y-63-92190

BRACKET,(L.H.)

|30

21Y-63-92290

BRACKET,(R.H.)

31

07283-22236

CLIP

32

01599-01011

NUT

33

01643-31032

WASHER
