Запчасти Komatsu PC128US-1 MONO-СТРЕЛА (СТРЕЛА¤РАБОЧ. ОСВЕЩЕНИЕ И ПАЛЕЦ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

21Y-70-00161

BOOM ASS'Y

1

BOOM

2

21Y-70-15A30

PLATE (WELDED)

|3

202-70-61XA0

BRACKET (WELDED)

3

BRACKET (WELDED)

4

203-46-41130

SEAT (WELDED)

5

203-70-66110

BUSHING

6

07145-00070

SEAL,DUST

7

07145-00070

SEAL,DUST

8

201-06-71280

WORK LAMP ASS'Y

|8

20Y-06-21480

WORK LAMP ASS'Y

9

203-06-56410

BRACKET

9A

01010-81225

BOLT

9B

01643-31232

WASHER

10

202-70-61210

PIN

11

21W-70-11310

PLATE

12

01010-81230

BOLT

13

01643-31232

WASHER

14

20U-70-31340

SPACER¤ 1.0MM

|14

203-70-11210

SPACER¤ 1.0MM

|14

20U-70-31330

SPACER¤ 0.5MM

|14

203-70-34270

SPACER¤ 0.5MM

15

202-70-61180

PIN

16

01019-11640

BOLT

17

01580-11613

NUT

18

21Y-70-14830

SPACER¤ 1.0MM

|18

203-70-41460

SPACER¤ 1.0MM

19

21K-70-11410

PLATE

20

203-70-61320

PIN

21

21W-70-11310

PLATE

22

01010-81230

BOLT

23

01643-31232

WASHER

24

21Y-70-14830

SPACER¤ 1.0MM

|24

203-70-41460

SPACER¤ 1.0MM

25

21Y-63-X2900

CYLINDER GROUP,L.H. (SEE FIG.Y1620-01A0)

|25

21Y-63-X2910

CYLINDER GROUP,R.H. (SEE FIG.Y1620-01A0)
