Запчасти Komatsu PC128US-1 ТОПЛИВН. БАК. (БАК) ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

21Y-04-11111

TANK

2

21W-04-21121

FLANGE

3

01220-40630

SCREW

4

01602-20619

WASHER,SPRING

5

07000-02015

O-RING

6

20U-04-21431

FLANGE

|6

21Y-04-11130

FLANGE

7

07700-50455

VALVE

|7

20Y-04-11130

VALVE

8

01220-40620

SCREW

9

01602-20619

WASHER,SPRING

10

07000-02018

O-RING

|10

07000-02015

O-RING

11

20B-04-21110

NIPPLE

12

21T-03-71270

ELBOW

|12

20G-68-12930

ELBOW

13

21Y-04-11390

SHEET

14

21Y-06-17120

SENSOR,FUEL

|14

7861-92-5820

SENSOR,FUEL

15

01252-40612

BOLT

16

01602-20619

WASHER,SPRING

17

07000-03048

O-RING

18

21Y-04-18100

VALVE ASS'Y

19

21Y-04-18150

SPACER

20

07000-12015

O-RING

21

07000-12014

O-RING

22

01010-80645

BOLT

23

01643-30623

WASHER

24

07288-01006

HOSE

25

198-09-31210

CLAMP

|25

07281-00197

CLAMP
