Запчасти Komatsu PC128US-1 ОХЛАЖД-Е (РАДИАТОР И МАСЛООХЛАДИТЕЛЬ) СИСТЕМА ОХЛАЖДЕНИЯ

1

203-03-67110

RADIATOR ASS'Y

2

203-03-41280

CAP

3

205-03-62660

PLUG

4

07000-01007

O-RING

5

203-03-56350

HOSE

6

20Y-03-11330

CLIP

7

01435-20814

BOLT

8

203-03-61320

SHEET

9

BRACKET

10

BRACKET

11

21Y-03-11111

OIL COOLER

12

01435-20816

BOLT

13

21Y-03-11270

SHEET

14

21Y-03-11371

NET

15

21Y-03-11361

SEAL

16

21Y-03-11351

NET

17

01434-10616

BOLT, WING,WING

18

01643-30623

WASHER

19

203-03-67122

SHROUD

20

01435-20816

BOLT

21

21Y-03-17210

COVER

22

21Y-03-17220

COVER

23

21Y-03-17230

COVER

24

01010-80814

BOLT

25

01643-30823

WASHER

26

21Y-03-11280

SHEET

27

21Y-54-17260

SEAL

28

21Y-03-17240

SEAL

29

21Y-03-17250

SEAL

30

21Y-03-17270

SEAL

31

21Y-03-17380

SHEET

32

21Y-03-17320

SHEET

33

21Y-03-17390

SHEET

34

21Y-03-17330

SHEET

35

08037-01610

GROMMET

36

21Y-03-17420

HOSE

37

206-03-43340

CLIP

38

21Y-03-17510

GUARD

39

01010-81225

BOLT

40

01643-31232

WASHER

41

21Y-03-17530

COVER

42

01010-81020

BOLT

43

01643-31032

WASHER
