Запчасти Komatsu PC128US-1 КАБИНА (/7) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$5

21W-54-00057

CAB ASS'Y

|$6

21W-54-00076

CAB ASS'Y,(WITH FRONT GUARD)

|$7

21W-54-00091

CAB ASS'Y,(WITH HEAD GUARD)

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-07A0.

1

CAB

1

CAB,(WITH FRONT GUARD)

1

CAB,(WITH HEAD GUARD)

2

20T-54-84750

WINDOW,L.H., UPPER

3

20U-54-24971

DAM,L.H., UPPER

4

20U-54-25151

TRIM

5

20T-54-84760

WINDOW,L.H., LOWER

6

20U-54-24981

DAM,L.H., LOWER

7

21W-54-34770

WINDOW,REAR

8

20U-54-24991

DAM

9

20U-54-25161

TRIM

10

20U-54-25162

SEAL

11

20U-54-24861

LINING,REAR

12

20U-54-24871

LINING,L.H.

13

20U-54-24881

LINING,R.H.

14

20U-54-25541

COVER,REAR

15

20U-54-25170

SEAL

16

20T-54-75121

DUCT

17

21W-54-14690

CLIP

18

20U-54-24681

TAPE

19

20U-54-25140

STOPPER

20

20T-54-84960

SHEET,NONSKID

21

20U-54-24711

GLASS

22

20U-54-24721

STRIP,WEATHER

23

20U-54-24733

WINDOW,UPPER

24

20U-54-24741

STRIP,WEATHER

25

20T-54-75210

GROMMET

26

08037-01008

GROMMET

27

08037-02512

GROMMET

27

08037-01610

GROMMET

28

09415-01008

CAP

29

09415-00706

CAP

30

01220-40412

SCREW

31

01641-20405

WASHER

32

01220-40612

SCREW

33

01641-20608

WASHER

34

01370-00412

SCREW
