Запчасти Komatsu PC128US-1 ОСНОВН. КЛАПАН (/8) (ОТВАЛLESS) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

723-36-16500

VALVE ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1660-01A0 T0 Y1660-08A0.

1

723-36-15151

PLUG

2

07000-11004

O-RING

3

07001-01004

RING

4

07002-11023

O-RING

5

01010-61680

BOLT

6

01010-61465

BOLT

7

01643-51645

WASHER

8

01010-80835

BOLT

9

07000-12012

O-RING

10

07000-13028

O-RING

11

07000-13035

O-RING

12

07040-12412

PLUG

13

07002-12434

O-RING

14

708-8E-16160

PLUG

15

07002-11023

O-RING

16

PLUG

17

COVER,A

18

COVER,B

19

723-36-15210

SLEEVE

20

723-36-15230

PISTON

21

723-36-15220

PISTON

22

723-36-15340

SPRING

23

723-36-15240

SPRING

24

723-36-15250

CASE

25

07000-13042

O-RING

26

01252-60820

BOLT

27

708-8E-16250

PLUG

28

07002-11823

O-RING
