Запчасти Komatsu PC128US-1 МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC128US-1 - МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
12
13
13
14
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37
37
37
38
38
38
39
40
41
42
42
43

Артикул

Название

Примечание

Количество

|$1

706-73-01181

MOTOR ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 AND Y1640-02A0.

|$4

706-73-03511

MOTOR SUB ASS'Y

1

706-73-43110

CASE,MOTOR

|$6

706-73-00020

HOUSING SUB ASS'Y

2

HOUSING

3

PLUG

4

706-73-40010

BEARING

5

706-73-42820

PIN

6

706-73-72680

PLUG

7

07002-11223

O-RING

8

709-25-11650

VALVE,CHECK

9

709-25-11361

SPRING

10

709-25-11640

PLUG

11

07000-12020

O-RING

12

706-73-72420

VALVE

13

706-73-72440

SPRING

14

706-73-72430

PLUG

15

07002-12434

O-RING

16

07000-02145

O-RING

17

01252-61240

BOLT

18

706-73-43960

SHAFT,DRIVE

19

706-73-43880

BEARING

20

706-73-43810

SPACER

21

706-73-43610

SPRING

22

706-73-43620

SEAT

23

706-73-43890

BEARING

24

706-73-05030

SPACER KIT

24

SPACER, 2.1MM

24

SPACER, 2.4MM

24

SPACER, 2.7MM

25

04064-03515

RING,SNAP

26

708-7T-12230

SEAL,OIL

27

04065-04518

RING,SNAP

28

706-73-43190

BLOCK,CYLINDER

29

706-73-43742

PLATE,VALVE

30

720-68-19610

PIN

31

706-73-43120

SHAFT,CENTER

32

706-73-43130

RING,CENTER

33

706-73-41110

SPRING

|$42

706-73-05020

RETAINER KIT

34

706-73-42260

RETAINER

35

706-73-42270

SCREW

36

706-73-43160

PISTON SUB ASS'Y

37

706-73-92340

PLATE

38

706-73-92350

DISK

39

706-73-92380

PISTON,BRAKE

40

706-73-92390

RING,BRAKE

41

07000-12115

O-RING

42

07000-12130

O-RING

43

708-7T-15150

SPRING

Выбрано товаров: 51
