Запчасти Komatsu PC128US-1 ОСНОВН. НАСОС (/8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-1L-00421

PUMP ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-08A0.

|$3

708-1L-01411

PUMP SUB ASS'Y

|$4

708-2L-04141

BLOCK ASS'Y,FRONT

1

BLOCK,CYLINDER

2

PLATE,VALVE

3

720-68-19610

PIN

4

04065-04818

RING,SNAP

5

708-2L-23131

SEAT

6

708-2L-33160

SPRING

7

708-7L-13140

SEAT

8

708-2L-23351

GUIDE,RETAINER

9

708-2L-23360

PIN

10

708-2L-33340

RETAINER,SHOE

11

708-2L-33310

PISTON SUB ASS'Y

|$16

708-2L-04361

CRADLE ASS'Y

12

CRADLE

13

CAM,ROCKER

14

04020-01228

PIN

15

07000-B1009

O-RING

16

01252-61230

BOLT

17

708-2L-24513

PISTON,SERVO

18

708-2L-24670

SEAL

18

708-2L-24612

SEAL

19

708-2L-24570

SLIDER

20

708-2L-24560

STOPPER

21

07000-B3040

O-RING

21

07000-13040

O-RING

22

07001-03040

RING,BACK-UP

23

708-2L-24522

COVER

24

01252-61445

BOLT

25

113-43-31380

WASHER

26

708-2L-24640

BOLT

27

708-2L-24650

NUT

28

708-2L-24630

SPRING

29

708-2L-24530

SCREW

30

708-2L-24620

O-RING

31

708-2L-24660

WASHER

32

708-2L-24590

NUT
