Запчасти Komatsu PC1250SP-8R ГЕНЕРАТОР (9AMP)(ВНУТР. ЧАСТИ)(9-9) A

|$1

600-861-9120

ALTERNATOR A,(90A)

1

KD0-35100-0310

ROTOR ASS'Y

2

KD1-33923-0890

COLLAR

3

KD1-35923-0030

COLLAR

4

KD0-09201-0770

BEARING,BALL

5

KD0-35300-0200

BRACKET ASS'Y,FRONT

6

KD0-35926-0080

RETAINER

7

KD0-35951-0080

PACKING

8

KD1-33926-0660

RETAINER

9

KD0-09201-0760

BEARING,BALL

10

KD1-33926-0790

RETAINER

11

KD0-35120-0250

FIELD COIL ASS'Y

12

KD0-35200-0320

STATOR ASS'Y

13

KD0-0083-08802

BOLT

|$15

KD0-35700-0970

BRACKET ASS'Y,REAR

14

KD0-35710-1190

BRACKET,REAR

15

KD0-35730-0162

RECTIFIER ASS'Y

16

KD0-35943-0210

BUSHING,INSULATE

17

KD0-33902-0090

NUT

18

KD0-33902-0080

NUT

19

KD1-0020-06452

SCREW

20

KD1-0330-06012

WASHER

21

KD1-0335-06002

WASHER,SPRING

22

KD0-0080-06142

BOLT

23

KD0-35943-0100

BUSHING,INSULATE

24

KD0-33902-0100

NUT

25

KD1-0335-08002

WASHER,SPRING

26

KD1-0331-08020

WASHER

27

KD0-0291-08010

NUT

28

KD0-0055-05122

SCREW

29

KD0-35761-0190

COVER

30

KD0-35719-0181

REGULATOR ASS'Y

31

KD0-35411-0650

PULLEY

32

KD0-35421-0190

FAN

33

KD1-0335-20002

WASHER,SPRING

34

KD0-0290-20022

NUT

35

KD1-35921-0010

WASHER
