Запчасти Komatsu PC1250SP-8R АНТИКОРРОЗ. ЭЛЕМЕНТ A

|$1

6217-61-8231

HEAD ASS'Y

1

6217-61-8211

HEAD,CORROSION

2

6217-61-8221

VALVE

3

07000-A2021

O-RING

4

600-411-1171

CARTRIDGE

5

01435-01035

BOLT

6

01436-01000

BOLT

7

6245-61-8110

PLATE

8

01435-01025

BOLT

9

6245-61-8210

TUBE,INLET

10

07206-31014

BOLT,JOINT

11

07005-01412

GASKET

12

6245-61-8130

TUBE,RETURN

13

07206-31014

BOLT,JOINT

14

07005-01412

GASKET

15

6166-75-6821

CLAMP,HALF

16

01435-00835

BOLT

17

01584-00806

NUT

18

6354-71-5630

BRACKET

19

01435-01020

BOLT

20

6166-75-6821

CLAMP,HALF

21

01435-00835

BOLT

22

6141-71-1710

JOINT

23

6127-71-5710

BOLT,JOINT

24

07005-01412

GASKET

25

6136-61-8510

JOINT

26

07206-31014

BOLT,JOINT

27

07005-01412

GASKET

28

07260-20922

HOSE

29

07281-00197

CLAMP

30

6141-71-1710

JOINT

31

07206-31014

BOLT,JOINT

32

07005-01412

GASKET

33

6245-61-8240

JOINT

34

07206-31014

BOLT,JOINT

35

07005-01412

GASKET

36

07260-20910

HOSE

37

07281-00197

CLAMP

38

6245-61-8230

TUBE

39

07206-31014

BOLT,JOINT

40

07005-01412

GASKET

41

6144-71-5760

JOINT

42

07206-31014

BOLT,JOINT

43

07005-01412

GASKET

44

07260-20910

HOSE

45

07281-00197

CLAMP
