Запчасти Komatsu PC1250SP-8R УПРАВЛ-Е ДВИГАТЕЛЕМLER (9-8) A

1

600-463-7100

CONTROLLER ASS'Y

|$2

600-463-7200

CONTROLLER ASS'Y (FOR HOT AREA SPEC.)

2

01435-00840

BOLT

3

6261-81-7100

COOLER

|$5

6261-81-7130

O-RING

|$6

02781-00420

UNION

|$7

07002-11823

O-RING

4

01435-01045

BOLT

5

6251-81-7210

CUSHION

6

02896-11012

O-RING

7

6245-71-5290

HOSE

8

6245-71-5310

HOSE

9

07206-31014

BOLT, JOINT

10

07005-01412

GASKET

11

6933-71-8220

CLIP

12

01010-81020

BOLT

13

01643-31032

WASHER

14

6245-21-6120

BRACKET

15

01435-01060

BOLT

16

01435-01025

BOLT

17

6245-81-5820

WIRE

18

01010-81020

BOLT

19

01643-31032

WASHER

20

600-051-2080

CLIP

21

01010-81020

BOLT

22

01643-31032

WASHER

23

426-06-11570

BRACKET

24

01011-81015

BOLT

25

01643-31032

WASHER

26

6934-71-5860

BRACKET

27

6130-12-4571

SPACER

28

6245-81-9350

COVER

29

01435-00820

BOLT

30

6245-81-9360

BRACKET

31

01435-00845

BOLT

32

6245-81-9390

COVER

33

6245-81-9380

COVER

34

01435-00820

BOLT

35

6261-81-2600

SENSOR

36

01252-60520

BOLT

37

6245-81-9210

BRACKET

38

01435-00820

BOLT
