Запчасти Komatsu PC1250SP-8R ТОПЛИВН. ФИЛЬТР. И ТРУБЫ (9-8) A

1

6261-71-6410

HEAD (1-5/8), FUEL FILTER

2

6110-73-6231

PLUG

3

07005-00812

GASKET

4

CARTRIDGE (1-5/8),(SEE FIG.A4119-A6A4)

5

01010-81040

BOLT

6

01643-31032

WASHER

7

6245-71-6160

TUBE, AIR BLOW

8

6245-71-5960

BOLT, JOINT

9

07005-00812

GASKET

10

07206-30506

BOLT, JOINT

11

07005-00812

GASKET

12

6245-71-5950

CLIP

13

01010-81020

BOLT

14

01643-31032

WASHER

14A

01643-31032

WASHER

15

6245-71-6240

BLOCK

16

6245-71-6340

BRACKET

17

01435-01045

BOLT

18

205-62-74690

NIPPLE

19

07002-11423

O-RING

20

6128-81-4810

VALVE

21

6245-71-6180

BOLT

22

6240-71-6530

CLAMP

23

6240-71-6540

CLAMP

24

01435-01040

BOLT

25

6245-71-6171

TUBE, BYPASS

26

07206-30508

BOLT, JOINT

27

07005-00812

GASKET

28

6245-71-5950

CLIP

29

01010-81020

BOLT

30

01643-31032

WASHER

30A

01643-31032

WASHER

31

6245-71-6520

JOINT

32

07206-31014

BOLT, JOINT

33

07005-01412

GASKET

34

6245-71-6540

HOSE

35

02896-11012

O-RING

36

6245-71-6450

JOINT

37

07043-70108

PLUG

38

04434-52711

CLIP

39

07095-20418

CUSHION

40

01010-81030

BOLT

41

01643-31032

WASHER

42

6245-71-6440

BRACKET

43

01011-81020

BOLT
