Запчасти Komatsu PC1250SP-8R БЛОК В СБОРЕ (ОХЛАЖД-Е)(С КОНДИЦИОНЕРОМ) Y

|$1

ND448800-5222

UNIT ASS'Y, COOLING

1

ND245450-2221

CASE, COOLING

2

ND245450-1721

CASE, COOLING

3

ND116569-5010

PLATE

4

ND447600-4970

EVAPORATOR

5

ND949142-0030

O-RING

6

ND116120-7990

CORE ASS'Y, HEATER

7

ND447500-1390

VALVE, EXPANSION

8

ND949046-2150

BOLT

9

ND446870-5650

TUBE, ACCESSORY

10

ND949142-0030

O-RING

11

ND949142-0010

O-RING

12

ND077500-0710

THERMISTOR

13

ND246690-2840

CLAMP

14

ND116650-8800

DOOR ASS'Y

15

ND116650-8820

DOOR ASS'Y

16

ND116650-8840

DOOR ASS'Y

17

ND116640-4652

DAMPER ASS'Y

18

ND443440-0030

SWITCH, PRESSURE

19

ND949142-0040

O-RING

20

ND446830-3880

TUBE

21

ND446810-9520

TUBE, SUCTION

22

ND949142-0030

O-RING

23

ND146678-4930

PACKING

24

ND949321-9940

GROMMET

25

ND246770-6990

CLAMP, PIPING

26

ND017231-1400

CLAMP

27

ND017660-3490

BRACKET

28

ND170400-4310

SENSOR ASS'Y, THERMO

29

ND146690-6020

CLAMP

30

ND246634-6010

BRACKET

31

ND499300-2051

I.C. POWER

32

ND063700-7200

SERVO MOTOR ASS'Y

33

ND063700-7210

SERVO MOTOR ASS'Y

34

ND116569-5020

PLATE

35

ND116682-0930

LEVER

36

ND116682-0960

LEVER

37

ND116662-4850

SHAFT

38

ND116569-5030

PLATE

39

ND116682-0940

LEVER

40

ND116682-0951

LEVER

41

ND116569-5041

PLATE

42

ND116569-5051

PLATE

43

ND116662-4860

SHAFT

44

ND116569-5062

PLATE
