Запчасти Komatsu PC1250SP-8R ОСНОВН. КЛАПАН (/)(5-СЕКЦИОНН.)(NO.) Y
2
3
13
4
9
15
10
12
1
14
34
5
24
6
25
11
33
16
28
8
23
7
22
17
31
29
27
26
21
30
20
19
18
32
37
38
39
36
41
35
42
43
40
№
Артикул
Название
Примечание
Количество
|$1
709-15-94000
CONTROL VALVE
|$2
THIS ASSEMBLY CONSISTS OF ALL PARTS
|$3
SHOWN IN FIGS.Y1665-01A0 TO Y1665-05A0.
|$4
709-90-71600
VALVE ASS'Y, SUCTION AND SAFETY
1
SLEEVE
2
SLEEVE
3
POPPET
4
PISTON
5
PLUG
6
POPPET
7
SCREW
8
SPACER
9
SPRING
10
SPRING
11
SPRING
12
SEAL
13
SEAL
14
O-RING
15
07002-03634
O-RING
16
O-RING
17
NUT
|$22
709-90-71700
VALVE ASS'Y, SUCTION AND SAFETY
18
SLEEVE
19
SLEEVE
20
POPPET
21
PISTON
22
PLUG
23
POPPET
24
SCREW
25
SPACER
26
SPRING
27
SPRING
28
SPRING
29
SEAL
30
SEAL
31
O-RING
32
07002-03634
O-RING
33
O-RING
34
NUT
|$40
700-90-74001
VALVE ASS'Y, SUCTION
35
SLEEVE
36
07002-03634
O-RING
37
VALVE
38
SEAL
39
SPRING
Выбрано товаров: 45
