Запчасти Komatsu PC1250SP-8R МОТОР ХОДА (БЛОК ЦИЛИНДРОВ И ПОРШЕНЬ В СБОРЕ)(/) Y

Схема запчастей Komatsu PC1250SP-8R - МОТОР ХОДА (БЛОК ЦИЛИНДРОВ И ПОРШЕНЬ В СБОРЕ)(/) Y
13
12
11
1
3
2
10
16
17
21
6
18
19
5
14
15
14
4
7
9
25
24
26
8
22
24
25
26
23
20

Артикул

Название

Примечание

Количество

|$1

21N-60-34100

MOTOR ASS'Y

1

KBB0441-02012

SHAFT

|$3

KBB0118-12048

CYLINDER BLOCK ASS'Y

2

CYLINDER BLOCK

3

PLATE.VALVE

4

KBB0112-01013

PISTON ASS'Y

5

PLATE.RETAINER (K4)

6

HOLDER.RETAINER (K4)

7

KBB0111-74046

PLATE

8

KB20461-69205

BALL. STEEL

9

KBB0111-13073

SPRING

10

KBB0141-69003

BEARING. ROLLER

11

KBB0141-69004

BEARING. ROLLER

12

KBB0111-18039

COLLAR

13

KB20461-61306

SPRING

14

KB20461-69603

PLATE. FRICTION

15

KB20461-69503

PLATE. DISK

16

KB20461-69602

PLATE. FRICTION

17

KBB0441-94007

PISTON. BRAKE

18

KB20461-75201

O-RING (K3)

19

KBB0141-51002

RING. BACK-UP (K3)

20

KB20461-65213

O-RING (K3)

21

KB20461-65104

RING. BACK-UP (K3)

22

KB20461-62103

SEAL (K3)

23

KB95123-26000

O-RING (K3)

24

KB95113-01000

O-RING (K3)

25

KB21961-95025

PLUG

26

KB95113-02400

O-RING (K3)

K3

KBB044A-51159

SEAL KIT

1

KB20461-62103

SEAL

|$31

KB20461-75201

O-RING

|$32

KBB0141-51002

RING, BACK-UP

|$33

KB20461-65213

O-RING

|$34

KB20461-65104

RING, BACK-UP

|$35

KB95123-26000

O-RING

|$36

KB95113-01000

O-RING

|$37

KB95113-02400

O-RING

K4

KBB011B-10003

PLATE, RETAINER, KIT

1

KBB0111-11006

PLATE, RETAINER

|$40

KBB0111-77002

HOLDER, RETAINER

Выбрано товаров: 40
