Запчасти Komatsu PC1250SP-8R МОТОР ПОВОРОТА (/) Y

|$1

706-7K-01230

Motor assembly

|$2

706-7K-03160

Motor subassembly

1

706-7K-41630

Shaft

2

706-7K-40080

Bearing

3

706-7K-41820

Spacer

4

706-77-42051

Spring

5

706-77-42041

Seat

6

706-7K-40070

Bearing

7

706-77-05070

Spacer Kit

|$10

Spacer, T=2.3mm

|$11

Spacer, T=2.4mm

|$12

Spacer, T=2.5mm

|$13

Spacer, T=2.7mm

|$14

Spacer, T=2.4mm

|$15

Spacer, T=2.6mm

|$16

Spacer, T=2.8mm

|$17

Spacer, T=2.9mm

8

04064-06525

Ring, snap

9

706-8J-41420

Seal oil

10

706-7K-41920

Spacer

11

04065-07525

Ring, snap

12

706-7K-41210

Cylinder block

13

706-7K-41710

Plate valve

14

708-18-13230

Pin

15

706-7K-41130

Shaft

16

706-77-42130

Ring

17

706-7K-41140

Spring

|$28

706-7K-05010

Retainer kit

18

Retainer

19

Screw

20

706-7K-41160

Piston subassembly

21

706-7K-91370

Plate

22

706-7K-91380

Plate

23

706-7K-91390

Disc

24

706-7K-91120

Piston, brake

25

07000-B5230

O-ring

26

706-7K-91130

Ring, brake

27

706-86-90290

O-ring

28

706-7K-91360

Spring
